QNAP 12-bay 12Gbps SAS-enabled High-performance NAS/iSCSI/IP-SAN Unified Storage

Name: QNAP 12-bay 12Gbps SAS-enabled High-performance NAS/iSCSI/IP-SAN Unified Storage
Brand: QNAP
SKU: 5RR686
Price: 8266.3 USD
Availability: InStock

QNAP

PCN#

5RR686

MFG#

TVSEC1280USASRP16GUS

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$8,266.30

Extended & Accidental Damage Protection Plans Available Details

2-Year $462.99

3-Year $582.99

Free Shipping

Estimated Shipment:

Product Highlights:

Intel Xeon E3
1246 v3 Quad
core (4 Core) 3.50 GHz
12 x HDD Supported
12 x SSD Supported
16 GB RAM DDR3 SDRAM
12Gb/s SAS Controller
RAID Supported
0, 1, 5, 6, 10, Hot Spare, JBOD RAID Levels
16 x Total Bays
16 x 2.5"/3.5" Bay
2 x Total Slot(s)
10 Gigabit Ethernet
8 USB Port(s)
4 USB 2.0 Port(s)
4 USB 3.0 Port(s)
Network (RJ
45)
QTS 4.2
HTTPS, HTTP, DNS, Telnet, IPv6, FTPS, SSL, WEBDAV, SSL/TLS, AFP, CIFS, ...
512 MB Flash Memory Capacity
2U

Product Condition: New and Factory Fresh

Limited Warranty2 Year

Shipping Weight: 48 lbs.

QNAP 12-bay 12Gbps SAS-enabled High-performance NAS/iSCSI/IP-SAN Unified Storage

Overview

Tech Specs

Specifications

Manufacturer	QNAP Systems
Manufacturer Part Number	TVS-EC1280U-SAS-RP-16G-US
Manufacturer Website Address	http://www.qnap.com
Brand Name	QNAP
Product Line	Turbo NAS
Product Series	TVS-ECx80U-SAS
Product Model	TVS-EC1280U-SAS-RP
Product Name	12-bay 12Gbps SAS-enabled High-performance NAS/iSCSI/IP-SAN Unified Storage
Marketing Information	QNAP TVS-EC1280U-SAS-RP is the world's first unified NAS supporting Auto Tiering to deliver ongoing optimization of data across high-performance SSD, 12Gbps SAS drives and high-capacity SATA disks. Powered by an Intel® Xeon E3 CPU, the 40GbE-ready TVS-EC1280U-SAS-RP delivers exceptional performance and supports cross-platform file sharing, comprehensive backup solutions, iSCSI & virtualization applications, and more practical business functions. With the powerful QTS operating system, the TVS-EC1280U-SAS-RP performs as a reliable, scalable and unbeatable unified and tiered storage solution for businesses. 3,800+ MB/s throughput and 260,000+ IOPS Qtier Technology drives Auto Tiering for optimal storage efficiency Built-in 256GB mSATA modules for caching, beneficial to IOPS-demanding applications Scalable design, up to 140 drives Virtualization-ready, centralized data storage, backup, sharing and disaster recovery Backward compatible with SAS/SATA 6Gbps drives 5 year warranty - Global warranty inclusive Enable Auto Tiering with Qtier Technology QNAP's Qtier Technology empowers the TVS-EC1280U-SAS-RP with Auto Tiering that helps continuously optimize storage efficiency. With Auto Tiering, the TVS-EC1280U-SAS-RP can automatically move hot data to high-performance storage tiers and cold data to lower-cost, higher-capacity drives, making the TVS-EC1280U-SAS-RP an extremely efficient shared resource. Businesses will no longer have to invest heavily in expensive Flash technology, but can still enjoy exceptional application performance and lower TCO of storage from Auto Tiering with the TVS-EC1280U-SAS-RP. 12Gbps DataBolt™ Advantage Implementing DataBolt technology, the TVS-EC1280U-SAS-RP can deliver twice the throughput for 6Gbps SAS drives by automatically aggregating the bandwidth from 3Gbps and 6Gbps drives to fully utilize 12Gbps, effectively accelerating the existing infrastructure. Excellent performance The TVS-EC1280U-SAS-RP supports 12Gbps SAS drives to provide fast data transmission speeds and drive up to 3,817 MB/s throughput and 260,441 IOPS. Powered by an Intel® Xeon® E3 v3 quad-core processor with 16GB or 8GB DDR3 ECC RAM, the TVS-EC1280U-SAS-RP greatly enhances the efficiency of CPU-demanding tasks and serves more concurrent tasks. SSD cache acceleration* The TVS-EC1280U-SAS-RP features 2 pre-installed 128GB mSATA modules, and there are no limits on using SSDs for caching. By installing high-performance SSDs, the IOPS performance of storage volumes can remarkably boost. It is perfect for improving overall workflow of random IOPS demanding applications such as database and virtualization. The internal cache port design reserves the space of hard drive tray for more storage capacity. Removable motherboard drawer for easy maintenance With the TVS-EC1280U-SAS-RP's removable motherboard drawer, IT administrators have easier access in upgrading/installing RAM, the internal cache, 40GbE adapter and other components. The motherboard itself can be removed and replaced without needing to remove the heavy TVS-EC1280U-SAS-RP from the rack cabinet, making it especially useful in maintaining the TVS-EC1280U-SAS-RP in data centers with multiple rack cabinets.
Product Type	SAN/NAS Storage System

Storage

Number of Hard Drives Supported	12
Number of Hard Drives Installed	No
Number of Solid State Drive Supported	12
Number of Solid State Drive Installed	No
Flash Memory Capacity	512 MB

Processor & Chipset

Processor Manufacturer	Intel
Processor Type	Xeon
Processor Model	E3-1246 v3
Processor Core	Quad-core (4 Core)
Processor Speed	3.50 GHz

Memory

Standard Memory	16 GB
Memory Technology	DDR3 SDRAM

Network & Communication

Ethernet Technology

10 Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	16
Number of 2.5"/3.5" Bays	16
Hot Swappable Bays	Yes
Total Number of Expansion Slots	2.0
Expansion Slot Type	PCI Express 3.0 x8 PCI Express 3.0 x4

Controllers

Controller Type	12Gb/s SAS
RAID Supported	Yes
RAID Levels	0, 1, 5, 6, 10, Hot Spare, JBOD

Interfaces/Ports

Total Number of USB Ports	8
Number of USB 2.0 Ports	4
Number of USB 3.0 Ports	4
Network (RJ-45)	Yes

Software

Operating System

QTS 4.2

Management & Protocols

Protocols

HTTPS
HTTP
DNS
Telnet
IPv6
FTPS
SSL
WEBDAV
SSL/TLS
AFP
CIFS
Bonjour
FTP
SMSC
DHCP
SSH
SMTP
FXP
SFTP
AFP 3.3
LDAP
NFSv3
iSCSI
TFTP
IPv4
UPnP
PPTP
TCP/IP
CIFS/SMB
DDNS
NFS
SNMP
RSync

Power Description

Number of Power Supplies Installed	2
Maximum Power Supply Wattage	450 W
Redundant Power Supply	Yes

Physical Characteristics

Height	3.5"
Width	17.4"
Depth	20.9"
Form Factor	Rack-mountable
Rack Height	2U
Weight (Approximate)	31.26 lb

Miscellaneous

Package Contents	12-bay 12Gbps SAS-enabled High-performance NAS/iSCSI/IP-SAN Unified Storage 4 x Ethernet Cables 2 x Power Cords 48 x Flat Head Screws (for 3.5" HDD) 48 x Flat Head Screws (for 2.5" HDD) Quick Installation Guide
Country of Origin	Taiwan

Warranty

Limited Warranty

2 Year
