StarTech.com 1-port PCI Express RS232 Serial Adapter Card - PCIe Serial DB9 Controller Card 16550 UART - Low Profile - Windows/Linux

Name: StarTech.com 1-port PCI Express RS232 Serial Adapter Card - PCIe Serial DB9 Controller Card 16550 UART - Low Profile - Windows/Linux
Brand: STARTECH
SKU: DN9011
Price: 45.34 USD
Availability: InStock

STARTECH

PCN#

DN9011

MFG#

PEX1S553LP

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$45.34

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $14.99

1-Year $10.99

Estimated Shipment:

Product Highlights:

1 port PCI Express RS232 serial controller card w/16550 UART/ASIX MCS9922CV
AA
Bi
directional speeds 921.6Kbps/port | 256 byte FIFO | Pin 9 pwr out 5v/12v/none
Expansion card w/low profile (Std bracket incl)
Win/Linux

Product Condition: New and Factory Fresh

Limited Warranty2 Year

Shipping Weight: 1 lbs.

StarTech.com 1-port PCI Express RS232 Serial Adapter Card - PCIe Serial DB9 Controller Card 16550 UART - Low Profile - Windows/Linux

Overview

Tech Specs

Specifications

Manufacturer	StarTech.com
Manufacturer Part Number	PEX1S553LP
Manufacturer Website Address	http://www.startech.com
Brand Name	StarTech.com
Product Model	PEX1S553LP
Product Name	1 Port Low Profile Native RS232 PCI Express Serial Card with 16550 UART
Marketing Information	The PEX1S553LP PCI Express Serial Card turns a PCI Express slot into an RS232 (DB9) serial connection. The card is constructed using a native single chip design that lets you harness the full capability offered by PCI Express (PCIe), while reducing the load applied to the CPU by as much as 48% over conventional bridge chip serial cards. The PCI Express RS232 Serial Adapter Card is compatible with a broad range of operating systems, including Windows® and Linux Kernel 2.6.11 to 4.11.x, and ships with a low profile/half-height bracket installed, but includes an optional full profile bracket that lets you add a serial port to virtually any computer (regardless of the case form factor). This product is a replacement for our PEX1S552LP card. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Type	Serial Adapter

Technical Information

Host Interface	PCI Express x1
Data Transfer Rate	460kB/s
UART Type	16550
Platform Supported	PC Mac Linux

Interfaces/Ports

Number of Serial Ports (External)

Physical Characteristics

Form Factor	Plug-in Card
Card Height	Low-profile
Height	0.8"
Width	3.1"
Length	4.1"
Weight (Approximate)	1.60 oz

Miscellaneous

Package Contents	1 Port Low Profile Native RS232 PCI Express Serial Card with 16550 UART Full Profile Bracket Driver CD Instruction Manual
Additional Information	Native single-Chip, single lane PCI Express; 48% less cpu load, and increased performance. Pre-configured for low profile/half-height systems but includes a full profile bracket for versatility. Easy to install and use with full step-by-step instructions saving time and hassle. Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), XP Embedded, POS Ready 2009, Embedded System 2009, CE 5.0/6.0, 2000, 98SE, 95, DOS Windows Server® 2012, 2008 R2, 2003 Mac OS® 10.4 and later (tested up to 10.10) Linux kernel 2.6.x
Environmentally Friendly	Yes
Environmental Certification	RoHS REACH WEEE
Country of Origin	Taiwan
TAA Compliant	Yes

Warranty

Limited Warranty

2 Year
